Ferrari 458 Speciale Aperta (Convertible) — Alternator - Starter Motor (diagram 042)
Exploded view of the alternator - starter motor on the Ferrari 458 Speciale Aperta (Convertible), with 38 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/042.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 301402 | Ferrari Alternator - 301402 | $2,196.50 | Special order, ships in 7-14 days |
| 2 | 253092 | Ferrari Alternator Brace Bracket - 253092 | $22.00 | Special order, ships in 7-14 days |
| 3 | 231620 | Ferrari/Maserati Screw - 231620 | $0.58 | In stock |
| 4 | 257220 | Ferrari Threaded Bushing - 257220 | $36.69 | Special order, ships in 7-14 days |
| 4 | 257217 | Ferrari Threaded Bushing - 257217 | $61.16 | Special order, ships in 7-14 days |
| 5 | 247088 | Ferrari Threaded Bushing - 247088 | $12.15 | Special order, ships in 7-14 days |
| 6 | 14308724 | Ferrari Allen Screw 10x100 - 14308724 | $6.75 | Available, ships in 3-6 days |
| 6 | 14308324 | Ferrari Screw - 14308324 | $3.68 | Special order, ships in 7-14 days |
| 7 | 10569474 | Ferrari Washer - 10569474 | $0.12 | Special order, ships in 7-14 days |
| 8 | 251220 | Ferrari 458 Serpentine Drive Belt - 251220 | $49.50 | In stock |
| 9 | 238587 | Ferrari 458/F12 Belt Tensioner - 238587 | $159.98 | In stock |
| 10 | 268567 | Ferrari Screw TE M8 x 60 - 268567 | $10.91 | Special order, ships in 7-14 days |
| 11 | 11193874 | Ferrari Washer D.8.4-16x1.4 - 11193874 | $0.12 | Available, ships in 3-6 days |
| 12 | 248743 | Ferrari 458/California/F12 Starter Motor - 248743 | $1,098.98 | In stock |
| 12 | 248743HT | Ferrari 458/California/F12 High Torque Starter Motor - 248743HT | $798.80 | In stock |
| 13 | 277661 | Ferrari Starter Motor Mounting Bracket - 277661 | $115.02 | Special order, ships in 7-14 days |
| 14 | 102741 | Ferrari/Maserati Nyloc Nut M6 - 102741 | $0.45 | In stock |
| 14 | 14040611 | Ferrari Nut M6 - 14040611 | $0.57 | Available, ships in 3-6 days |
| 14 | 12575421 | Ferrari Nyloc Nut M6 x 6 - 12575421 | $0.40 | Available, ships in 3-6 days |
| 15 | 248471 | Ferrari Screw 8x20 - 248471 | $2.07 | Available, ships in 3-6 days |
| 16 | 260062 | Ferrari Shield Fastener Bracket - 260062 | $29.34 | Special order, ships in 7-14 days |
| 17 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 18 | 259433 | Ferrari Heat Shield - 259433 | $416.09 | Available, ships in 3-6 days |
| 19 | 231621 | Ferrari Allen Screw M6 x 30 TCEI - 231621 | $0.73 | Available, ships in 3-6 days |
| 20 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 21 | 227894 | Ferrari/Maserati Belt Pulley - 227894 | $174.99 | In stock |
| 24 | 238590 | Ferrari/Maserati Belt Pulley - 238590 | $66.38 | In stock |
| 25 | 260886 | Ferrari Screw 10X1.5X20 - 260886 | $7.80 | Available, ships in 3-6 days |
| 26 | 13550224 | Ferrari Washer D 6.15-13x1 - 13550224 | $2.59 | Available, ships in 3-6 days |
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 12575411 | Ferrari Nyloc Nut M6 x 6 - 12575411 | Superseded | Order 12575421 instead | |
| 216568 | Ferrari Screw 6x30 - 216568 | Superseded | Order 231621 instead | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 257521 | Ferrari Starter Motor Mounting Bracket - 257521 | Superseded | Order 277661 instead | |
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead |
