Ferrari 488 Pista — [VEHICLE TRIM] - E.12 - ROLLBAR (diagram 0108)

Exploded view of the [vehicle trim] - e.12 - rollbar on the Ferrari 488 Pista, with 67 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 488 Pista [VEHICLE TRIM] - E.12 - ROLLBAR exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
87630012Ferrari Mostrina Fianchetto Sellata - 87630012$318.18Special order, ships in 7-14 days
87630312Ferrari Mostrina Fianchetto Sellata - 87630312$318.18Special order, ships in 7-14 days
87630612Ferrari Mostrina Panchetta Sellata D - 87630612$318.18Special order, ships in 7-14 days
87630912Ferrari Mostrina Panchetta Sellata S - 87630912$318.18Special order, ships in 7-14 days
87631812Ferrari Ricoprimento Piastra Sup.Est - 87631812$318.18Special order, ships in 7-14 days
87631212Ferrari Ricoprimento Piastra Sup.Int - 87631212$318.18Special order, ships in 7-14 days
87631512Ferrari Ricoprimento Piastra Sup.Int - 87631512$318.18Special order, ships in 7-14 days
80415900Ferrari Screw - 80415900$32.60Available, ships in 3-6 days
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
12646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
126648Ferrari Washer - 126648SupersededOrder 14496624 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
1750882Ferrari Complete Roll Bar Frame - 750882$9,110.35Special order, ships in 7-14 days
2783755Ferrari Compl. RH Bench Cover Panel - 783755SupersededOrder 884816 instead
2783782Ferrari Compl. RH Bench Cover Panel - 783782SupersededOrder 884817 instead
2884816Ferrari Compl. RH Bench Cover Panel - 884816$562.96Special order, ships in 7-14 days
2884817Ferrari Compl. RH Bench Cover Panel - 884817$391.61Special order, ships in 7-14 days
287630600Ferrari Mostrina Panchetta Sellata D - 87630600SupersededOrder 87630612 instead
3783740Ferrari Compl. LH Bench Cover Panel - 783740SupersededOrder 884814 instead
3783743Ferrari Compl. LH Bench Cover Panel - 783743SupersededOrder 884815 instead
3884814Ferrari Compl. LH Bench Cover Panel - 884814$562.96Special order, ships in 7-14 days
3884815Ferrari Compl. LH Bench Cover Panel - 884815$391.61Special order, ships in 7-14 days
387630900Ferrari Mostrina Panchetta Sellata S - 87630900SupersededOrder 87630912 instead
487630000Ferrari Mostrina Fianchetto Sellata - 87630000SupersededOrder 87630012 instead
4783814Ferrari RH Flank Cover Panel - 783814SupersededOrder 884819 instead
4803938Ferrari RH Flank Cover Panel - 803938SupersededOrder 884824 instead
4884819Ferrari RH Flank Cover Panel - 884819$391.61Special order, ships in 7-14 days
4884824Ferrari RH Flank Cover Panel - 884824$562.96Special order, ships in 7-14 days
5783804Ferrari LH Flank Cover Panel - 783804SupersededOrder 884818 instead
5803931Ferrari LH Flank Cover Panel - 803931SupersededOrder 884823 instead
5884818Ferrari LH Flank Cover Panel - 884818$391.61Special order, ships in 7-14 days
5884823Ferrari LH Flank Cover Panel - 884823$562.96Special order, ships in 7-14 days
587630300Ferrari Mostrina Fianchetto Sellata - 87630300SupersededOrder 87630312 instead
614372574Ferrari Bracket - 14372574$2.80Special order, ships in 7-14 days
684583500Ferrari Fastener clip - 84583500$2.59Available, ships in 3-6 days
7783877Ferrari RH Upper Outer Plate Cover - 783877SupersededOrder 884822 instead
7884822Ferrari RH Upper Outer Plate Cover - 884822$367.14Special order, ships in 7-14 days
7911166Ferrari RH Upper Outer Plate Cover - 911166$514.01Special order, ships in 7-14 days
7911174Ferrari RH UPPER OUTER PLATE COVER - 911174Price on requestContact us for price and availability
787632100Ferrari Ricoprimento Piastra Sup.Est - 87632100Price on requestContact us for price and availability
8783863Ferrari LH Upper Outer Plate Cover - 783863SupersededOrder 884883 instead
8884883Ferrari LH Upper Outer Plate Cover - 884883$367.14Special order, ships in 7-14 days
8911165Ferrari LH Upper Outer Plate Cover - 911165$514.01Special order, ships in 7-14 days
8911173Ferrari LH UPPER OUTER PLATE COVER - 911173Price on requestContact us for price and availability
887631800Ferrari Ricoprimento Piastra Sup.Est - 87631800SupersededOrder 87631812 instead
9783870Ferrari RH Upper Inner Plate Cover - 783870SupersededOrder 884821 instead
9884821Ferrari RH Upper Inner Plate Cover - 884821$367.14Special order, ships in 7-14 days
9911163Ferrari RH Upper Inner Plate Cover - 911163$465.04Special order, ships in 7-14 days
9911172Ferrari RH UPPER INNER PLATE COVER - 911172Price on requestContact us for price and availability
987631500Ferrari Ricoprimento Piastra Sup.Int - 87631500SupersededOrder 87631512 instead
10783835Ferrari LH Upper Inner Plate Cover - 783835SupersededOrder 884820 instead
10884820Ferrari LH Upper Inner Plate Cover - 884820$367.14Special order, ships in 7-14 days
10911161Ferrari LH Upper Inner Plate Cover - 911161$489.54Special order, ships in 7-14 days
10911171Ferrari LH UPPER INNER PLATE COVER - 911171Price on requestContact us for price and availability
1087631200Ferrari Ricoprimento Piastra Sup.Int - 87631200SupersededOrder 87631212 instead
11127496Ferrari Spring Washer 8mm - 127496$0.12Available, ships in 3-6 days
1267278400Ferrari BRACKET - 67278400$21.60Special order, ships in 7-14 days
1315689809Ferrari Screw D. 4.2 x 19 TBFIC - 15689809$0.27Available, ships in 3-6 days
1385692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
13169815Ferrari Screw TBFEI M5 x 20 - 169815$3.47Available, ships in 3-6 days
1485833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
1516287524Ferrari Flanged Bolt M8 x 40 - 16287524$2.59Available, ships in 3-6 days
1511617624Ferrari Screw - 11617624SupersededOrder 16287224 instead
1516287224Ferrari Screw M8x25 - 16287224$0.82Available, ships in 3-6 days
1714496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
