Ferrari Daytona SP3 — [ENGINE] - B.12 - ENGINE OIL PUMP (diagram 0017)

Exploded view of the [engine] - b.12 - engine oil pump on the Ferrari Daytona SP3, with 23 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Daytona SP3 [ENGINE] - B.12 - ENGINE OIL PUMP exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
14305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
812435Ferrari Compl. Oil Pump - 812435Price on requestContact us for price and availability
231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
14306624Ferrari Screw 8x35mm - 14306624$0.52Special order, ships in 7-14 days
155010660Ferrari Compl. Oil Pump - 55010660$8,273.30Special order, ships in 7-14 days
155042138Ferrari Compl. Oil Pump - 55042138$8,914.93Special order, ships in 7-14 days
1910383Ferrari Compl. Oil Pump - 910383Price on requestContact us for price and availability
1955008Ferrari Compl. Oil Pump - 955008Price on requestContact us for price and availability
214306421Ferrari Screw 8x20 - 14306421$0.63Available, ships in 3-6 days
214306424Ferrari Screw M8 x 25mm - 14306424SupersededOrder 14306421 instead
311198074Ferrari/Maserati Washer - 11198074$0.14In stock
414306621Ferrari Screw 8X35 - 14306621SupersededOrder 14306624 instead
5292495Ferrari Calibrated Stud Bolt - 292495$44.24Special order, ships in 7-14 days
6833135Ferrari Compl. Oil Pump Delivery Fit - 833135$100.78Special order, ships in 7-14 days
7833133Ferrari Bracket - 833133$49.14Special order, ships in 7-14 days
8248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
9917921Ferrari Hexagonal Oil Pump Drive Rod - 917921$76.19Special order, ships in 7-14 days
9920843Ferrari Hexagonal Oil Pump Drive Rod - 920843$66.35Special order, ships in 7-14 days
10275528Ferrari Pump Seal Filter - 275528$58.98Available, ships in 3-6 days
11123353Ferrari O-Ring - 123353$4.35Available, ships in 3-6 days
12986847Ferrari Conical Washer - 986847$1.36Special order, ships in 7-14 days
12986899Ferrari Washer - 986899SupersededOrder 986847 instead

All Daytona SP3 diagrams
