Ferrari Daytona SP3 — [MECHANICAL SYSTEM] - D.06 - EMISSIONS CONTROL SYSTEM (diagram 0054)

Exploded view of the [mechanical system] - d.06 - emissions control system on the Ferrari Daytona SP3, with 48 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Daytona SP3 [MECHANICAL SYSTEM] - D.06 - EMISSIONS CONTROL SYSTEM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
14305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
302979Ferrari Bracket With Sheath - 302979SupersededOrder 307048 instead
14039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
252813Ferrari Shim - 252813SupersededOrder 264020 instead
210653Ferrari Spacer - 210653SupersededOrder 264020 instead
12601224Ferrari Washer - 12601224SupersededOrder 12601274 instead
12605370Ferrari Washer - 12605370SupersededOrder 12601274 instead
12605371Ferrari Washer - 12605371SupersededOrder 12601274 instead
680232Ferrari Washer - 680232SupersededOrder 12601274 instead
12605374Ferrari Wavy Washer - 12605374SupersededOrder 12601274 instead
1247795Ferrari Secondary Air Pump - 247795$1,229.39Special order, ships in 7-14 days
2253769Ferrari Clip - 253769$1.17Special order, ships in 7-14 days
3906089Ferrari Secondary Air Pump Mounting - 906089$31.93Special order, ships in 7-14 days
411625714Ferrari SCREW - 11625714$1.02Special order, ships in 7-14 days
515896214Ferrari Nut M6 x 5 - 15896214SupersededOrder 14039614 instead
611194674Ferrari Washer - 11194674$0.92Available, ships in 3-6 days
7846678Ferrari Secondary Air System Pipe Co - 846678$442.56Special order, ships in 7-14 days
8282849Ferrari Pressure Sensor - 282849$61.16Special order, ships in 7-14 days
9307048Ferrari Bracket With Sheath - 307048$83.57Special order, ships in 7-14 days
10789570Ferrari Compl. Pipe Bracket - 789570$68.83Special order, ships in 7-14 days
11233600Ferrari/Maserati Screw - 233600$1.98In stock
12797723Ferrari Screw - 797723$0.86Special order, ships in 7-14 days
13844995Ferrari Compl. Pipe For Pre-Assembly - 844995$2,060.69Special order, ships in 7-14 days
14248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
1516286124Ferrari Screw M6x20 - 16286124$0.71Special order, ships in 7-14 days
1610442190Ferrari P Clip Bracket With Sheath - 10442190$1.42Available, ships in 3-6 days
17777837Ferrari Secondary Air System Pipe Fa - 777837$29.48Special order, ships in 7-14 days
18231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
1916286524Ferrari Screw - 16286524$1.30Available, ships in 3-6 days
20202980Ferrari Gasket - 202980$4.89Available, ships in 3-6 days
21309014Ferrari Clip - 309014$1.80Available, ships in 3-6 days
2211628424Ferrari Screw 6X14 - 11628424$1.28Special order, ships in 7-14 days
23763505Ferrari Clip Set - 763505$3.91Special order, ships in 7-14 days
24331918Ferrari Compl. LH Secondary Air Inlet - 331918$467.15Special order, ships in 7-14 days
25284235Ferrari Secondary Air System Valve - 284235$417.97Available, ships in 3-6 days
2655018763Ferrari RH Secondary Air System Valv - 55018763$43.68Special order, ships in 7-14 days
26264020Ferrari RH Spacer Assembly - 264020$110.61Special order, ships in 7-14 days
2755018779Ferrari LH Secondary Air System Valv - 55018779$32.76Special order, ships in 7-14 days
27286011Ferrari LH Spacer Assembly - 286011$98.32Special order, ships in 7-14 days
28186781Ferrari/Maserati Secondary Air Gasket - 186781$6.05In stock
29331919Ferrari RH Secondary Air Pipe Mounting Bracket - 331919$19.89Special order, ships in 7-14 days
30331920Ferrari LH Secondary Air Pipe Mounting Bracket - 331920$19.89Special order, ships in 7-14 days
31177576Ferrari Cable Grommet - 177576$4.12Available, ships in 3-6 days
32183898Ferrari Bush - 183898$5.44Special order, ships in 7-14 days
3312601274Ferrari Wavy Washer 6mm - 12601274$1.04Available, ships in 3-6 days
3410902824Ferrari Screw M6 x 30 - 10902824$0.17Available, ships in 3-6 days
35331917Ferrari Compl. RH Secondary Air Inlet - 331917$491.74Special order, ships in 7-14 days

All Daytona SP3 diagrams
