Ferrari Daytona SP3 — [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK (diagram 0064)
Exploded view of the [mechanical system] - d.15 - expansion tank on the Ferrari Daytona SP3, with 40 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0064.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 198253 | Ferrari Clip - 198253 | $7.40 | Special order, ships in 7-14 days | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 216568 | Ferrari Screw 6x30 - 216568 | Superseded | Order 231621 instead | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead | |
| 1 | 948290 | Ferrari COMPL. HEADER TANK CAP - 948290 | Price on request | Contact us for price and availability |
| 2 | 145030 | Ferrari Radiator Cap - 145030 | $89.98 | In stock |
| 3 | 817484 | Ferrari Rubber Pipe - 817484 | $29.48 | Special order, ships in 7-14 days |
| 4 | 787524 | Ferrari Rubber Pipe - 787524 | $12.02 | Special order, ships in 7-14 days |
| 5 | 859199 | Ferrari Three Way Pipe - 859199 | $393.38 | Special order, ships in 7-14 days |
| 6 | 318032 | Ferrari Rubber Pipe - 318032 | $41.76 | Special order, ships in 7-14 days |
| 7 | 859205 | Ferrari Compl. Header Tank Rigid Pip - 859205 | $295.03 | Special order, ships in 7-14 days |
| 8 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 9 | 797723 | Ferrari Screw - 797723 | $0.86 | Special order, ships in 7-14 days |
| 10 | 773401 | Ferrari RUBBER PIPE - 773401 | Price on request | Contact us for price and availability |
| 11 | 262107 | Ferrari Screw Collar - 262107 | $3.26 | Special order, ships in 7-14 days |
| 12 | 794191 | Ferrari Header Tank Bracket - 794191 | $117.99 | Special order, ships in 7-14 days |
| 13 | 10441690 | Ferrari P Clip D18mm - 10441690 | $3.91 | Special order, ships in 7-14 days |
| 14 | 779282 | Ferrari Compl. Clip - 779282 | $3.91 | Special order, ships in 7-14 days |
| 15 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 16 | 785506 | Ferrari Rubber Pipe - 785506 | $100.78 | Special order, ships in 7-14 days |
| 17 | 13125270 | Ferrari Collare A Nastro Fiss.Manic. - 13125270 | $3.68 | Special order, ships in 7-14 days |
| 18 | 785504 | Ferrari Moulded Pipe - 785504 | $238.47 | Special order, ships in 7-14 days |
| 19 | 206536 | Ferrari Clip D.14 - 206536 | $0.92 | Special order, ships in 7-14 days |
| 20 | 10449890 | Ferrari Bracket With Sheath - 10449890 | $4.16 | Special order, ships in 7-14 days |
| 21 | 287818 | Ferrari Stud Bolt - 287818 | $34.40 | Special order, ships in 7-14 days |
| 22 | 785501 | Ferrari Engine Side Rubber Pipe - 785501 | $61.45 | Special order, ships in 7-14 days |
| 23 | 295423 | Ferrari Adhesive Foam - 295423 | $1.69 | Special order, ships in 7-14 days |
| 24 | 789830 | Ferrari Rear Header Tank Mounting Br - 789830 | $63.90 | Special order, ships in 7-14 days |
| 25 | 103549 | Ferrari Grommet - 103549 | $2.80 | In stock |
| 26 | 149707 | Ferrari Spacer - 149707 | $2.13 | Available, ships in 3-6 days |
| 27 | 231621 | Ferrari Allen Screw M6 x 30 TCEI - 231621 | $0.73 | Available, ships in 3-6 days |
| 28 | 797730 | Ferrari Screw - 797730 | $1.17 | Special order, ships in 7-14 days |
| 29 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 30 | 12644404 | Ferrari Washer - 12644404 | Superseded | Order 12644424 instead |
| 30 | 12644424 | Ferrari Washer 6.15-15 x 1 - 12644424 | $0.12 | Available, ships in 3-6 days |
