Ferrari Daytona SP3 — [MECHANICAL SYSTEM] - D.24 - ABS ASR SYSTEM (diagram 0074)
Exploded view of the [mechanical system] - d.24 - abs asr system on the Ferrari Daytona SP3, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [MECHANICAL SYSTEM] - D.24 - ABS ASR SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0074.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days | |
| 1 | 841318 | Ferrari HYDRAULIC UNIT - 841318 | Price on request | Contact us for price and availability |
| 2 | 817193 | Ferrari ECU Mounting Bracket - 817193 | $103.25 | Special order, ships in 7-14 days |
| 3 | 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days |
| 4 | 199592 | Ferrari Clip - 199592 | $7.19 | Special order, ships in 7-14 days |
| 5 | 307688 | Ferrari Yaw Sensor - 307688 | $437.10 | Special order, ships in 7-14 days |
| 6 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
