Ferrari Daytona SP3 — [VEHICLE TRIM] - E.53 - OTHER INTERIOR TRIM ACCESSORIES (diagram 0165)
Exploded view of the [vehicle trim] - e.53 - other interior trim accessories on the Ferrari Daytona SP3, with 28 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [VEHICLE TRIM] - E.53 - OTHER INTERIOR TRIM ACCESSORIES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0165.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 82654500 | Ferrari 2KG Fire Extinguisher - 82654500 | Superseded | Order 922429 instead | |
| 83490400 | Ferrari 2KG Fire Extinguisher - 83490400 | Superseded | Order 922429 instead | |
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 73325000 | Ferrari LH Seat Belt - 73325000 | $1,737.89 | Special order, ships in 7-14 days | |
| 73325100 | Ferrari RH Seat Belt - 73325100 | $1,762.37 | Special order, ships in 7-14 days | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days | |
| 1 | 862826 | Ferrari Compl. Rear View Mirror - 862826 | $3,665.56 | Special order, ships in 7-14 days |
| 2 | 89124800 | Ferrari LH Seat Belt - 89124800 | Superseded | Order 73325000 instead |
| 2 | 89124900 | Ferrari RH Seat Belt - 89124900 | Superseded | Order 73325100 instead |
| 3 | 812973 | Ferrari Seat Belt Buckle Stalk - 812973 | $320.06 | Special order, ships in 7-14 days |
| 4 | 83717300 | Ferrari SCREW HEAD COVER - 83717300 | $10.25 | Special order, ships in 7-14 days |
| 5 | 85980900 | Ferrari Buckle Cover - 85980900 | $492.43 | Special order, ships in 7-14 days |
| 6 | 812974 | Ferrari LH 4-Point Seat Belt - 812974 | $6,488.63 | Special order, ships in 7-14 days |
| 6 | 812975 | Ferrari RH 4-Point Seat Belt - 812975 | $6,488.63 | Special order, ships in 7-14 days |
| 7 | 83911900 | Ferrari Retractor Screw - 83911900 | $3.47 | Special order, ships in 7-14 days |
| 8 | 795717 | Ferrari LH Hsab Jss - 795717 | $1,352.32 | Special order, ships in 7-14 days |
| 8 | 795718 | Ferrari RH Hsab JSS - 795718 | $1,352.32 | Special order, ships in 7-14 days |
| 9 | 750033 | Ferrari LH Airbag Bracket - 750033 | $123.09 | Special order, ships in 7-14 days |
| 9 | 750034 | Ferrari RH Airbag Bracket - 750034 | $120.62 | Special order, ships in 7-14 days |
| 10 | 14040614 | Ferrari Flanged Nut 6mm - 14040614 | $0.27 | Available, ships in 3-6 days |
| 11 | 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days |
| 12 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 13 | 922429 | Ferrari 2KG FIRE EXTINGUISHER - 922429 | $1,081.84 | Special order, ships in 7-14 days |
| 15 | 975389 | Ferrari EXTINGUISHER TRIM KIT - 975389 | Price on request | Contact us for price and availability |
| 15 | 975390 | Ferrari EXTINGUISHER TRIM KIT - 975390 | Price on request | Contact us for price and availability |
| 16 | 949710 | Ferrari RH-LH Shoulder Cover Kit - 949710 | $417.97 | Special order, ships in 7-14 days |
