Ferrari Daytona SP3 — [VEHICLE TRIM] - E.57.02 - AC SYSTEM - AIR CONDITIONER SYSTEM (diagram 0170)

Exploded view of the [vehicle trim] - e.57.02 - ac system - air conditioner system on the Ferrari Daytona SP3, with 73 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Daytona SP3 [VEHICLE TRIM] - E.57.02 - AC SYSTEM - AIR CONDITIONER SYSTEM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
284800Ferrari AC Heating Pipe Connector Elbow On Chassis Bulkhead - 284800$1,688.93Special order, ships in 7-14 days
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
14305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
262112Ferrari Collar - 262112SupersededOrder 262111 instead
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
13442484Ferrari Gasket - 13442484SupersededOrder 11342484 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
216568Ferrari Screw 6x30 - 216568SupersededOrder 231621 instead
10860270Ferrari Screw Collar - 10860270$1.94Available, ships in 3-6 days
10860370Ferrari Screw Collar - 10860370$3.26Special order, ships in 7-14 days
13127770Ferrari Screw Collar - 13127770$2.82Special order, ships in 7-14 days
268210Ferrari Screw Collar - 268210$6.32Special order, ships in 7-14 days
1871019Ferrari Hose From Heater To Radiator - 871019$492.43Special order, ships in 7-14 days
2308291Ferrari AC Heating Pipe Connector Elbow On Chassis Bulkhead - 308291$1,649.69Special order, ships in 7-14 days
381895900Ferrari Gasket - 81895900$14.62Special order, ships in 7-14 days
4262108Ferrari Screw Collar - 262108$3.47Special order, ships in 7-14 days
5302813Ferrari Water Pipe From TGK To Idle - 302813$935.64Special order, ships in 7-14 days
6262109Ferrari Screw Collar - 262109$2.01Available, ships in 3-6 days
6262111Ferrari Screw Collar - 262111$3.03Special order, ships in 7-14 days
7291332Ferrari Idle Pump Inlet Connector Pipe - 291332$270.83Special order, ships in 7-14 days
8291349Ferrari Idle Water Recirculation Pump - 291349$5,509.80Special order, ships in 7-14 days
982268600Ferrari Clip - 82268600$4.12Special order, ships in 7-14 days
10302805Ferrari U-Pipe From Pump To AC Unit - 302805$443.17Special order, ships in 7-14 days
11240729Ferrari Hose - 240729$295.43Available, ships in 3-6 days
1267635900Ferrari/Maserati Right TGK Valve - 67635900$359.75In stock
1382329200Ferrari Anti-Vibration Rubber Block - 82329200$2.38Special order, ships in 7-14 days
14821842Ferrari Hvac Unit Valve Mounting Bra - 821842$164.95Special order, ships in 7-14 days
1562771900Ferrari Screw D. 4.2 x 16 TBIC - 62771900$0.54Available, ships in 3-6 days
16302812Ferrari Connector Pipe - 302812$418.56Special order, ships in 7-14 days
17951331Ferrari Underbody Water Pipe For Hea - 951331$443.17Special order, ships in 7-14 days
18871022Ferrari Hose From Thermostat To Unde - 871022$123.09Special order, ships in 7-14 days
19871089Ferrari Underbody Freon Vapour Pipe - 871089$763.27Special order, ships in 7-14 days
20871093Ferrari Underbody Compressor Freon P - 871093$911.01Special order, ships in 7-14 days
21265097Ferrari Screw 8X40 - 265097$14.84Special order, ships in 7-14 days
2214040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
2313839624Ferrari Screw - 13839624$7.63Special order, ships in 7-14 days
24871088Ferrari Hvac-Underbody Pipe With Cha - 871088$1,674.30Special order, ships in 7-14 days
25871084Ferrari Hvac-Dryer Filter Pipe With - 871084$1,378.85Special order, ships in 7-14 days
2614040711Ferrari Nut M8 - 14040711$0.79Available, ships in 3-6 days
27248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
28256323Ferrari Screw 5x16 - 256323$0.98Available, ships in 3-6 days
29262559Ferrari Clip - 262559$1.78Available, ships in 3-6 days
3010441290Ferrari P Clip Bracket With Sheath 28mm D.10 - 10441290$1.02Available, ships in 3-6 days
31896351Ferrari Condenser-Filter Gas Pipe - 896351$664.78Special order, ships in 7-14 days
3267085100Ferrari/Maserati Dehydrating Filter - 67085100$73.54In stock
33817084Ferrari Dehydrator Filter Bracket - 817084$96.01Special order, ships in 7-14 days
3411626124Ferrari Screw 6x25 - 11626124SupersededOrder 11612826 instead
3411612826Ferrari Screw M6 x 25 - 11612826$6.75Available, ships in 3-6 days
3511625824Ferrari Screw 6x18 - 11625824$0.71Available, ships in 3-6 days
3681649400Ferrari Clip - 81649400$18.17Special order, ships in 7-14 days
37871087Ferrari Underbody Condenser Pipe - 871087$763.27Special order, ships in 7-14 days
38893260Ferrari Underbody Freon Pipe - 893260$664.78Special order, ships in 7-14 days
39231621Ferrari Allen Screw M6 x 30 TCEI - 231621$0.73Available, ships in 3-6 days
40893261Ferrari Underbody Compressor Freon P - 893261$763.27Special order, ships in 7-14 days
41910443Ferrari Freon Pipe Bracket - 910443$31.99Special order, ships in 7-14 days
42231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
43920886Ferrari Retaining Clip - 920886$0.82Special order, ships in 7-14 days
44145854Ferrari Cable tie 200mm - 145854$0.57Available, ships in 3-6 days
45305752Ferrari Rubber Spacer - 305752$179.44Special order, ships in 7-14 days
46295279Ferrari Plug 5mm - 295279$2.38Special order, ships in 7-14 days
47236847Ferrari Ambient Temperature Sensor - 236847$113.32In stock
48894731Ferrari Temperature Sensor Bracket - 894731$120.62Special order, ships in 7-14 days
4915957701Ferrari Screw - 15957701Price on requestContact us for price and availability
5085692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
5114450484Ferrari Gasket - 14450484$10.48Special order, ships in 7-14 days
5210318884Ferrari Gasket - 10318884$10.46Special order, ships in 7-14 days
5311342484Ferrari Gasket - 11342484$10.46Special order, ships in 7-14 days
5411342784Ferrari Washer 3/4" - 11342784$19.42Available, ships in 3-6 days
5511084384Ferrari Gasket - 11084384$20.51Special order, ships in 7-14 days
5614450683Ferrari Gasket - 14450683$10.48Special order, ships in 7-14 days
5710319184Ferrari Gasket - 10319184$10.48Available, ships in 3-6 days
5811342584Ferrari Washer 1/2" - 11342584$19.42Available, ships in 3-6 days
