Ferrari Daytona SP3 — [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM (diagram 0183)

Exploded view of the [electrical system] - f.08 - various fastenings for the electrical system on the Ferrari Daytona SP3, with 55 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Daytona SP3 [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
14305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
14039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
14048115Ferrari Nut - 14048115SupersededOrder 14058411 instead
14048611Ferrari Nut - 14048611SupersededOrder 14058411 instead
14048615Ferrari Nut - 14048615SupersededOrder 14058411 instead
10442290Ferrari P Clip Bracket With Sheath - 10442290$1.42Special order, ships in 7-14 days
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
1888375Ferrari Airbag ECU Cover Bracket - 888375$76.30Special order, ships in 7-14 days
214040611Ferrari Nut M6 - 14040611$0.57Available, ships in 3-6 days
3179309Ferrari ADHESIVE FOAM - 179309$8.28Available, ships in 3-6 days
410441990Ferrari P Clip Bracket With Sheath - 10441990$1.42Available, ships in 3-6 days
5231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
6323137Ferrari Bracket With Sheath - 323137$46.69Special order, ships in 7-14 days
710442090Ferrari P Clip Bracket With Sheath D26 - 10442090$1.42Available, ships in 3-6 days
813579101Ferrari Washer - 13579101$0.06Available, ships in 3-6 days
9910688Ferrari Clamp - 910688$0.84Special order, ships in 7-14 days
10159147Ferrari Rubber Shim 100x50x4mm - 159147$1.67Available, ships in 3-6 days
1185692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
12244219Ferrari Clip - 244219$8.72Special order, ships in 7-14 days
13899480Ferrari Self-Locking Nut M4 - 899480$0.84Special order, ships in 7-14 days
1485692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
1510441590Ferrari P Clip Bracket With Sheath 16mm - 10441590$0.98Available, ships in 3-6 days
16797723Ferrari Screw - 797723$0.86Special order, ships in 7-14 days
17810791Ferrari FASTENER BRACKET - 810791Price on requestContact us for price and availability
18291225Ferrari P clip Bracket With Sheath - 291225$7.86Special order, ships in 7-14 days
1914058411Ferrari Flanged Nut M6 x 6mm - 14058411$0.38Available, ships in 3-6 days
2085833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
2110441890Ferrari P Clip Bracket With Sheath D22 - 10441890$1.17Available, ships in 3-6 days
22217854Ferrari CLAMP - 217854$0.52Available, ships in 3-6 days
2310442190Ferrari P Clip Bracket With Sheath - 10442190$1.42Available, ships in 3-6 days
2414039511Ferrari Nut - 14039511$0.54Available, ships in 3-6 days
2510441690Ferrari P Clip D18mm - 10441690$3.91Special order, ships in 7-14 days
2610448890Ferrari Bracket With Sheath - 10448890$4.16Available, ships in 3-6 days
2711673111Ferrari Nut - 11673111$0.52Available, ships in 3-6 days
2714084111Ferrari Nut - 14084111SupersededOrder 11673111 instead
2814058521Ferrari Nut - 14058521$3.68Special order, ships in 7-14 days
2914040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
3084487000Ferrari CLIP - 84487000$6.96Special order, ships in 7-14 days
3114059111Ferrari Flanged Nut M5 - 14059111$0.08Available, ships in 3-6 days
3261712500Ferrari P Clip Bracket - 61712500$2.29In stock
3314059311Ferrari NUT - 14059311$0.52Available, ships in 3-6 days
3462940900Ferrari Allen Head Screw M6 x 15 TBEI - 62940900$2.59Available, ships in 3-6 days
35145854Ferrari Cable tie 200mm - 145854$0.57Available, ships in 3-6 days
36256323Ferrari Screw 5x16 - 256323$0.98Available, ships in 3-6 days
37287818Ferrari Stud Bolt - 287818$34.40Special order, ships in 7-14 days
3886174900Ferrari Washer - 86174900$4.35Special order, ships in 7-14 days
39225821Ferrari Clip - 225821$6.10Special order, ships in 7-14 days
4013046012Ferrari Nut - 13046012SupersededOrder 13046011 instead
41291408Ferrari Clip - 291408$0.34Special order, ships in 7-14 days
42860456Ferrari AIRBAG RESISTOR - 860456$295.03Special order, ships in 7-14 days

All Daytona SP3 diagrams
