Ferrari F8 Spider — [ENGINE] - B.22 - FORCED INDUCTION SYSTEM TURBOCHARGERS AND MOUNTS (diagram 0027)
Exploded view of the [engine] - b.22 - forced induction system turbochargers and mounts on the Ferrari F8 Spider, with 35 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [ENGINE] - B.22 - FORCED INDUCTION SYSTEM TURBOCHARGERS AND MOUNTS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0027.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 765021 | Ferrari LH Cylinder Head Heat Shield - 765021 | Superseded | Order 918239 instead | |
| 769613 | Ferrari RH Cylinder Head Heat Shield - 769613 | Superseded | Order 918238 instead | |
| 315957 | Ferrari RH Turbo Heat Shield - 315957 | $173.76 | Special order, ships in 7-14 days | |
| 765057 | Ferrari RH Turbo Heat Shield - 765057 | $168.88 | Special order, ships in 7-14 days | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 1 | 767450 | Ferrari RH Exhaust Manifold - 767450 | $9,541.84 | Special order, ships in 7-14 days |
| 2 | 342067 | Ferrari LH Exhaust Manifold - 342067 | $10,465.77 | Special order, ships in 7-14 days |
| 3 | 340485 | Ferrari RH Turbocharger - 340485 | Superseded | Order 343098 instead |
| 3 | 343098 | Ferrari RH Turbocharger - 343098 | $36,595.03 | Contact us to order |
| 4 | 340486 | Ferrari LH Turbocharger - 340486 | Superseded | Order 343099 instead |
| 4 | 343099 | Ferrari LH Turbocharger - 343099 | $36,595.03 | Contact us to order |
| 5 | 292736 | Ferrari/Maserati Exhaust Manifold Gasket - 292736 | $149.98 | In stock |
| 6 | 307964 | Ferrari Exhaust Manifold Nut - 307964 | $4.48 | In stock |
| 7 | 314780 | Ferrari Steel Ring Seal - 314780 | $350.16 | Available, ships in 3-6 days |
| 8 | 313303 | Ferrari Turbo-Manifold Fastener V-Clamp - 313303 | Superseded | Order 287210 instead |
| 8 | 287210 | Ferrari V-Clamp For Fastening Catalytic Converter To Turbo - 287210 | $83.15 | Available, ships in 3-6 days |
| 9 | 309013 | Ferrari 488 Turbo Flange Gasket - 309013 | $126.85 | In stock |
| 10 | 828860 | Ferrari RH Turbo Heat Shield - 828860 | $167.40 | Special order, ships in 7-14 days |
| 11 | 859941 | Ferrari LH Turbo Heat Shield - 859941 | $172.33 | Special order, ships in 7-14 days |
| 12 | 12646624 | Ferrari Washer 6.15-15x1.5 - 12646624 | $0.40 | Available, ships in 3-6 days |
| 13 | 238108 | Ferrari/Maserati Spring Washer - 238108 | $0.80 | In stock |
| 14 | 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days |
| 14 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 15 | 14305234 | Ferrari Allen Head Bolt M6 x 16 - 14305234 | $0.50 | Available, ships in 3-6 days |
| 16 | 10261060 | Ferrari/Maserati Copper Crush Washer - 10261060 | $0.26 | In stock |
| 17 | 290216 | Ferrari Threaded Connector With Seal Ring - 290216 | $44.29 | Special order, ships in 7-14 days |
| 18 | 918238 | Ferrari RH Cylinder Head Heat Shield - 918238 | $911.01 | Special order, ships in 7-14 days |
| 19 | 918239 | Ferrari LH Cylinder Head Heat Shield - 918239 | $911.01 | Special order, ships in 7-14 days |
| 20 | 231627 | Ferrari Screw M8 x 16 - 231627 | $1.25 | Available, ships in 3-6 days |
| 21 | 337120 | Ferrari RH Exhaust Manifold Heat Shi - 337120 | $174.80 | Special order, ships in 7-14 days |
| 22 | 340546 | Ferrari LH Exhaust Manifold Heat Shi - 340546 | $174.80 | Special order, ships in 7-14 days |
| 23 | 233600 | Ferrari/Maserati Screw - 233600 | $1.98 | In stock |
| 24 | 342239 | Ferrari Speed Sensor - 342239 | $437.10 | Special order, ships in 7-14 days |
| 25 | 14304124 | Ferrari Screw TCEI M5 x 12 - 14304124 | $0.31 | Special order, ships in 7-14 days |
