Ferrari F8 Spider — [MECHANICAL SYSTEM] - D.3 - ENGINE INJECTION CONTROL (diagram 0050)
Exploded view of the [mechanical system] - d.3 - engine injection control on the Ferrari F8 Spider, with 28 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [MECHANICAL SYSTEM] - D.3 - ENGINE INJECTION CONTROL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0050.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 216568 | Ferrari Screw 6x30 - 216568 | Superseded | Order 231621 instead | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 1 | 861912 | Ferrari Centralina Accensione Med17. - 861912 | $2,552.45 | Special order, ships in 7-14 days |
| 2 | 310876 | Ferrari Ecu Bracket - 310876 | $152.62 | Special order, ships in 7-14 days |
| 2 | 912665 | Ferrari Motronic ECU Bracket - 912665 | $115.69 | Special order, ships in 7-14 days |
| 3 | 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days |
| 3 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 4 | 865036 | Ferrari Ion ECU Casing - 865036 | $2,248.03 | Special order, ships in 7-14 days |
| 5 | 310877 | Ferrari Ecu Mounting Bracket - 310877 | $59.07 | Special order, ships in 7-14 days |
| 6 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 7 | 882697 | Ferrari Compl. Front Oxygen Sensor - 882697 | $284.51 | Special order, ships in 7-14 days |
| 8 | 900650 | Ferrari Compl. Front Oxygen Sensor - 900650 | $284.51 | Special order, ships in 7-14 days |
| 9 | 882699 | Ferrari Compl. Rear Oxygen Sensor - 882699 | $207.90 | Special order, ships in 7-14 days |
| 10 | 340691 | Ferrari Pressure Sensor - 340691 | $196.67 | Special order, ships in 7-14 days |
| 11 | 231621 | Ferrari Allen Screw M6 x 30 TCEI - 231621 | $0.73 | Available, ships in 3-6 days |
| 12 | 14040614 | Ferrari Flanged Nut 6mm - 14040614 | $0.27 | Available, ships in 3-6 days |
| 13 | 13125470 | Ferrari Collar - 13125470 | Superseded | Order 13126970 instead |
| 14 | 766508 | Ferrari Tubo Gomma D7-14/D5-12X140 9 - 766508 | $128.01 | Special order, ships in 7-14 days |
| 15 | 13126970 | Ferrari Collar - 13126970 | $3.03 | Available, ships in 3-6 days |
| 16 | 769841 | Ferrari Tubo Gomma Sil.D.7-14X34 90G - 769841 | $56.60 | Special order, ships in 7-14 days |
| 17 | 340699 | Ferrari T Union - 340699 | Superseded | Order 913829 instead |
| 17 | 913829 | Ferrari Three Way - 913829 | $10.06 | Special order, ships in 7-14 days |
| 18 | 766511 | Ferrari Tubo Gomma Sil. D.7-14X120 - 766511 | $56.60 | Special order, ships in 7-14 days |
| 19 | 766512 | Ferrari Tubo Gomma Sil. D.7-14X190 - 766512 | $66.45 | Special order, ships in 7-14 days |
| 20 | 769845 | Ferrari Tubo Gomma Sil.D.7-14X70 90G - 769845 | $66.45 | Special order, ships in 7-14 days |
| 21 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
