Ferrari F8 Tributo — [ENGINE] - B.23 - FORCED INDUCTION SYSTEM PIPES (diagram 0028)
Exploded view of the [engine] - b.23 - forced induction system pipes on the Ferrari F8 Tributo, with 29 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [ENGINE] - B.23 - FORCED INDUCTION SYSTEM PIPES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0028.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 308430 | Ferrari Pipe Union - 308430 | Superseded | Order 315276 instead | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 1 | 322814 | Ferrari Water Delivery Pipe To RH Tu - 322814 | $393.93 | Special order, ships in 7-14 days |
| 2 | 327480 | Ferrari Water Delivery Pipe To LH Tu - 327480 | $369.30 | Special order, ships in 7-14 days |
| 3 | 337498 | Ferrari Oil Return Pipe From RH Turb - 337498 | $541.67 | Special order, ships in 7-14 days |
| 4 | 327479 | Ferrari Oil Return Pipe From LH Turb - 327479 | $590.91 | Special order, ships in 7-14 days |
| 5 | 337130 | Ferrari Oil Delivery Pipe To RH Turb - 337130 | $664.78 | Special order, ships in 7-14 days |
| 6 | 337131 | Ferrari Oil Delivery Pipe To LH Turb - 337131 | $664.78 | Special order, ships in 7-14 days |
| 7 | 317597 | Ferrari Water Return Pipe From RH Turbo - 317597 | $110.78 | Special order, ships in 7-14 days |
| 8 | 317598 | Ferrari Water Return Pipe From LH Turbo - 317598 | $137.87 | Special order, ships in 7-14 days |
| 9 | 308429 | Ferrari Pipe Union - 308429 | $20.16 | Available, ships in 3-6 days |
| 10 | 10261060 | Ferrari/Maserati Copper Crush Washer - 10261060 | $0.26 | In stock |
| 11 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 12 | 315276 | Ferrari Pipe Union - 315276 | $31.99 | Special order, ships in 7-14 days |
| 13 | 10260160 | Ferrari Copper Washer D. 10 - 14 x 1 - 10260160 | $1.99 | Available, ships in 3-6 days |
| 14 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 15 | 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days |
| 16 | 308203 | Ferrari Gasket - 308203 | $39.31 | Available, ships in 3-6 days |
| 17 | 287722 | Ferrari O-Ring 15.08 x 2.62 - 287722 | $9.81 | Available, ships in 3-6 days |
| 18 | 14456981 | Ferrari 360/430 Gearbox Cover O-Ring - 14456981 | $1.81 | In stock |
| 19 | 318497 | Ferrari Rubber Pipe - 318497 | $86.15 | Special order, ships in 7-14 days |
| 20 | 318500 | Ferrari Rubber Pipe - 318500 | $73.85 | Special order, ships in 7-14 days |
| 21 | 13125470 | Ferrari Collar - 13125470 | Superseded | Order 13126970 instead |
| 22 | 178052 | Ferrari Clip - 178052 | $3.26 | Available, ships in 3-6 days |
| 22 | 296778 | Ferrari Screw Collar 16- 27mm - 296778 | Superseded | Order 178052 instead |
| 23 | 768361 | Ferrari Tubaz.Rig.Raffr.Aux.Ed Att.W - 768361 | $911.01 | Special order, ships in 7-14 days |
| 24 | 768362 | Ferrari Tubo Mandata Nourice - 768362 | $61.52 | Special order, ships in 7-14 days |
