Ferrari F80 — [ENGINE] - B.18 - FUEL PUMPS (diagram 0023)
Exploded view of the [engine] - b.18 - fuel pumps on the Ferrari F80, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [ENGINE] - B.18 - FUEL PUMPS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0023.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 1 | 889811 | Ferrari Fuel Pump - 889811 | $1,138.08 | Special order, ships in 7-14 days |
| 2 | 859262 | Ferrari Pump Soundproofing Cover - 859262 | $319.62 | Special order, ships in 7-14 days |
| 3 | 331787 | Ferrari HIGH PRESSURE PUMP CAM FOLLOWER - 331787 | $105.70 | Special order, ships in 7-14 days |
| 4 | 876113 | Ferrari Fuel Pipe - 876113 | $162.25 | Available, ships in 3-6 days |
| 5 | 836236 | Ferrari Bracket - 836236 | $71.28 | Special order, ships in 7-14 days |
| 6 | 840912 | Ferrari COMPL. RH FUEL PIPE FASTENER BRACKET - 840912 | Price on request | Contact us for price and availability |
| 7 | 840913 | Ferrari COMPL. LH FUEL PIPE FASTENER BRACKET - 840913 | Price on request | Contact us for price and availability |
| 8 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 9 | 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days |
| 10 | 14306434 | Ferrari Screw M8x25 - 14306434 | $0.71 | Special order, ships in 7-14 days |
| 11 | 12638524 | Ferrari Flat Washer 8.15x15x1.5 - 12638524 | $0.12 | Available, ships in 3-6 days |
