Ferrari F80 — [ENGINE] - B.22 - FORCED INDUCTION SYSTEM TURBOCHARGERS AND MOUNTS (diagram 0027)
Exploded view of the [engine] - b.22 - forced induction system turbochargers and mounts on the Ferrari F80, with 48 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [ENGINE] - B.22 - FORCED INDUCTION SYSTEM TURBOCHARGERS AND MOUNTS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0027.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 3 | 55009399 | Ferrari Outer LH Manifold Heat Shiel - 55009399 | $935.64 | Special order, ships in 7-14 days |
| 3 | 55009400 | Ferrari Outer RH Manifold Heat Shiel - 55009400 | $935.64 | Special order, ships in 7-14 days |
| 4 | 55002249 | Ferrari RIPARO INTERNO COLLETTORE SCARICO DX - 55002249 | $837.14 | Special order, ships in 7-14 days |
| 4 | 55002248 | Ferrari RIPARO INTERNO COLLETTORE SCARICO SX - 55002248 | $837.14 | Special order, ships in 7-14 days |
| 5 | 275465 | Ferrari Gasket - 275465 | $103.25 | Available, ships in 3-6 days |
| 6 | 792541 | Ferrari Gasket - 792541 | $284.51 | Special order, ships in 7-14 days |
| 7 | 957187 | Ferrari Turbo-Manifold Fastener V-Cl - 957187 | $1,255.72 | Special order, ships in 7-14 days |
| 8 | 14059214 | Ferrari Flanged Nut M6 - 14059214 | $0.38 | Available, ships in 3-6 days |
| 9 | 797724 | Ferrari Screw - 797724 | $0.92 | Special order, ships in 7-14 days |
| 10 | 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days |
| 10 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 11 | 953586 | Ferrari Exhaust Manifold Gasket - 953586 | $100.78 | Special order, ships in 7-14 days |
| 12 | 210971 | Ferrari Copper Exhaust Nut - 210971 | $3.25 | In stock |
| 13 | 55034019 | Ferrari COMPL. TURBO MOUNT - 55034019 | Price on request | Contact us for price and availability |
| 14 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 15 | 815958 | Ferrari Vite Flangiata Rib. M8X1.25X - 815958 | $16.83 | Special order, ships in 7-14 days |
| 16 | 55062756 | Ferrari Heat Shield Above Turbocharg - 55062756 | $8,050.40 | Special order, ships in 7-14 days |
| 17 | 55034283 | Ferrari SCREW - 55034283 | Price on request | Contact us for price and availability |
| 18 | 55034406 | Ferrari LH MOUNT BRACKET - 55034406 | Price on request | Contact us for price and availability |
| 18 | 55034407 | Ferrari RH MOUNT BRACKET - 55034407 | Price on request | Contact us for price and availability |
| 19 | 55026103 | Ferrari STUD BOLT - 55026103 | $121.82 | Special order, ships in 7-14 days |
| 20 | 14058419 | Ferrari Flanged Nut - 14058419 | $1.61 | Special order, ships in 7-14 days |
| 21 | 962206 | Ferrari LH Connector Shield - 962206 | $224.04 | Special order, ships in 7-14 days |
| 21 | 962205 | Ferrari RH Connector Shield - 962205 | $224.04 | Special order, ships in 7-14 days |
| 22 | 797723 | Ferrari Screw - 797723 | $0.86 | Special order, ships in 7-14 days |
| 23 | 744106 | Ferrari HEAT SHIELD BRACKET - 744106 | Price on request | Contact us for price and availability |
| 24 | 797705 | Ferrari SCREW - 797705 | $14.85 | Special order, ships in 7-14 days |
| 25 | 780327 | Ferrari LH BRACKET - 780327 | Price on request | Contact us for price and availability |
| 25 | 780328 | Ferrari RH BRACKET - 780328 | Price on request | Contact us for price and availability |
| 26 | 55002926 | Ferrari LH CABLE MOUNTING BRACKET - 55002926 | Price on request | Contact us for price and availability |
| 26 | 55002927 | Ferrari RH CABLE MOUNT BRACKET - 55002927 | Price on request | Contact us for price and availability |
| 27 | 954302 | Ferrari LH Inverter - 954302 | $17,367.15 | Contact us to order |
| 27 | 954301 | Ferrari RH Inverter - 954301 | $17,367.15 | Contact us to order |
| 28 | 976073 | Ferrari CAVO MASSA INVERTER EAT - 976073 | $155.10 | Special order, ships in 7-14 days |
| 29 | 233600 | Ferrari/Maserati Screw - 233600 | $1.98 | In stock |
| 30 | 225408 | Ferrari Cylindrical Bushing - 225408 | $12.99 | Special order, ships in 7-14 days |
| 31 | 831824 | Ferrari SCREW - 831824 | Price on request | Contact us for price and availability |
| 32 | 831900 | Ferrari Cap - 831900 | $110.78 | Special order, ships in 7-14 days |
| 33 | 950117 | Ferrari Araymond Retainer Block - 950117 | $29.52 | Special order, ships in 7-14 days |
| 34 | 886127 | Ferrari CABLE MOUNTING BRACKET - 886127 | Price on request | Contact us for price and availability |
| 35 | 10442090 | Ferrari P Clip Bracket With Sheath D26 - 10442090 | $1.42 | Available, ships in 3-6 days |
| 36 | 994214 | Ferrari PUMP CABLE BRACKET - 994214 | Price on request | Contact us for price and availability |
| 37 | 994121 | Ferrari REAR MOUNTING BRACKET - 994121 | Price on request | Contact us for price and availability |
| 38 | 201137 | Ferrari SCREW - 201137 | Price on request | Contact us for price and availability |
| 39 | 837574 | Ferrari Stud Bolt - 837574 | $20.37 | Special order, ships in 7-14 days |
