Ferrari F80 — [GEARBOX] - C.1 - GEARBOX AND FASTENERS (diagram 0040)
Exploded view of the [gearbox] - c.1 - gearbox and fasteners on the Ferrari F80, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [GEARBOX] - C.1 - GEARBOX AND FASTENERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0040.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 93798 | Ferrari Washer - 93798 | Superseded | Order 10519624 instead | |
| 10519601 | Ferrari Washer 8.15-17 X 2 - 10519601 | Superseded | Order 10519624 instead | |
| 1 | 55015547 | Ferrari COMPL. DCT GEARBOX - 55015547 | Price on request | Contact us to order |
| 2 | 899610 | Ferrari Compl. RH Rear Strut - 899610 | $5,015.95 | Special order, ships in 7-14 days |
| 3 | 990220 | Ferrari COMPL. MOUNTING STRUT - 990220 | Price on request | Contact us for price and availability |
| 4 | 247857 | Ferrari Screw 8x35 - 247857 | $4.12 | Available, ships in 3-6 days |
| 5 | 14306634 | Ferrari Screw - 14306634 | Price on request | Contact us for price and availability |
| 6 | 14499401 | Ferrari Washer - 14499401 | $0.54 | Available, ships in 3-6 days |
| 6 | 14499424 | Ferrari Washer - 14499424 | Superseded | Order 14499401 instead |
| 7 | 955543 | Ferrari COMPL. REAR SPACER - 955543 | Price on request | Contact us for price and availability |
| 8 | 955093 | Ferrari Pin - 955093 | $228.97 | Special order, ships in 7-14 days |
| 9 | 955251 | Ferrari GEARBOX MOUNT SPACER - 955251 | Price on request | Contact us for price and availability |
| 10 | 14306834 | Ferrari Screw - 14306834 | $1.88 | Special order, ships in 7-14 days |
| 11 | 810134 | Ferrari Retention Bracket - 810134 | $418.56 | Special order, ships in 7-14 days |
| 12 | 14306734 | Ferrari Screw - 14306734 | $2.13 | Special order, ships in 7-14 days |
| 13 | 10519624 | Ferrari Washer 8.15 - 17 x 2 - 10519624 | $0.27 | Available, ships in 3-6 days |
| 14 | 954378 | Ferrari Compl. Vent Block - 954378 | $443.17 | Special order, ships in 7-14 days |
| 15 | 11903811 | Ferrari Banjo Bolt M10 x 1.25 - 11903811 | $8.05 | Special order, ships in 7-14 days |
| 16 | 10284460 | Ferrari Washer - 10284460 | $0.31 | Available, ships in 3-6 days |
| 17 | 14059421 | Ferrari Flanged Nut 10x1.25 - 14059421 | $0.92 | Available, ships in 3-6 days |
