Ferrari F80 — [GEARBOX] - C.03.02 - GEARBOX OIL HEAT EXCHANGER AND PIPES - HEAT EXCHANGER AND REAR PIPES (diagram 0044)

Exploded view of the [gearbox] - c.03.02 - gearbox oil heat exchanger and pipes - heat exchanger and rear pipes on the Ferrari F80, with 26 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari F80 [GEARBOX] - C.03.02 - GEARBOX OIL HEAT EXCHANGER AND PIPES - HEAT EXCHANGER AND REAR PIPES exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
262112Ferrari Collar - 262112SupersededOrder 262111 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
10860370Ferrari Screw Collar - 10860370$3.26Special order, ships in 7-14 days
13127770Ferrari Screw Collar - 13127770$2.82Special order, ships in 7-14 days
268210Ferrari Screw Collar - 268210$6.32Special order, ships in 7-14 days
248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
1954600Ferrari Gearbox Pipe Shield - 954600$517.04Special order, ships in 7-14 days
2987344Ferrari RIPARO SX CONNETTORI CAMBIO - 987344$492.43Special order, ships in 7-14 days
3816731Ferrari FRONT FASTENER BRACKET FOR RH SHIELD - 816731Price on requestContact us for price and availability
414305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
4231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
511625524Ferrari Screw - 11625524$1.53Special order, ships in 7-14 days
611625714Ferrari SCREW - 11625714$1.02Special order, ships in 7-14 days
755037002Ferrari REAR FASTENER BRACKET FOR LH SHIELD - 55037002Price on requestContact us for price and availability
855060836Ferrari SOLENOID SHIELD - 55060836Price on requestContact us for price and availability
9202484Ferrari SCREW - 202484Price on requestContact us for price and availability
10202479Ferrari WASHER - 202479Price on requestContact us for price and availability
1155055934Ferrari Water Delivery Pipe On Gearb - 55055934$1,969.79Special order, ships in 7-14 days
12904357Ferrari Water Return Pipe On Gearbox - 904357$1,723.56Special order, ships in 7-14 days
13262111Ferrari Screw Collar - 262111$3.03Special order, ships in 7-14 days
14803918Ferrari Gasket 1.78 x 20. - 803918$2.59Available, ships in 3-6 days
1555055938Ferrari PIPE MOUNTING BRACKET - 55055938Price on requestContact us for price and availability
1655009376Ferrari PIPE MOUNTING BRACKET - 55009376Price on requestContact us for price and availability
1710441890Ferrari P Clip Bracket With Sheath D22 - 10441890$1.17Available, ships in 3-6 days
18231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
