Ferrari F80 — [MECHANICAL SYSTEM] - D.25.04 - FRONT SUSPENSION - COOLING (diagram 0079)

Exploded view of the [mechanical system] - d.25.04 - front suspension - cooling on the Ferrari F80, with 63 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari F80 [MECHANICAL SYSTEM] - D.25.04 - FRONT SUSPENSION - COOLING exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
14305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
840561Ferrari Oil Pump - 840561SupersededOrder 917721 instead
14432221Ferrari Screw - 14432221SupersededOrder 231619 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
14432224Ferrari Screw M6 x 22 - 14432224SupersededOrder 231619 instead
12643707Ferrari Washer - 12643707SupersededOrder 12643778 instead
12643777Ferrari Washer - 12643777SupersededOrder 12643778 instead
155009338Ferrari SUSPENSION SYSTEM COOLING OIL TANK - 55009338Price on requestContact us for price and availability
2968627Ferrari Oil Tank Cap - 968627$22.62Special order, ships in 7-14 days
313837017Ferrari Screw 6X30 - 13837017$7.19Special order, ships in 7-14 days
412643778Ferrari Washer 6-18 x 1.5 - 12643778$0.54Available, ships in 3-6 days
5103549Ferrari Grommet - 103549$2.80In stock
6149707Ferrari Spacer - 149707$2.13Available, ships in 3-6 days
7952022Ferrari Tank Inlet Hose - 952022$81.23Special order, ships in 7-14 days
8952005Ferrari Tank Outlet Hose - 952005$81.23Special order, ships in 7-14 days
9971139Ferrari Collar - 971139$5.04Special order, ships in 7-14 days
10958172Ferrari Heat Exchanger Oil Outlet Pi - 958172$344.69Special order, ships in 7-14 days
11958316Ferrari Suspension Cooling Heat Exch - 958316$960.25Special order, ships in 7-14 days
12248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
1355018882Ferrari ACTIVE SUSPENSION HEAT EXCHANGER - 55018882Price on requestContact us for price and availability
14797725Ferrari Screw - 797725$1.82Special order, ships in 7-14 days
15917721Ferrari Oil Pump - 917721$1,551.20Special order, ships in 7-14 days
16903825Ferrari Pump-Active Suspension Filte - 903825$224.04Special order, ships in 7-14 days
17950846Ferrari PUMP MOUNTING BRACKET - 950846Price on requestContact us for price and availability
18265097Ferrari Screw 8X40 - 265097$14.84Special order, ships in 7-14 days
1914040714Ferrari Flanged Nut - 14040714$1.25Available, ships in 3-6 days
2012646727Ferrari Washer D. 8.45 X 20 X 2 - 12646727$0.40Available, ships in 3-6 days
21901367Ferrari Oil Filter - 901367$262.62Special order, ships in 7-14 days
22779638Ferrari Pump Suction Pipe - 779638$566.30Special order, ships in 7-14 days
23256323Ferrari Screw 5x16 - 256323$0.98Available, ships in 3-6 days
24180137Ferrari/Maserati Water Temperature Sender / Sensor - 180137$25.19In stock
25216851Ferrari O-Ring - 216851$5.44Special order, ships in 7-14 days
26958304Ferrari Pump Outlet Hose - 958304$115.69Special order, ships in 7-14 days
27776040Ferrari BRACKET FASTENING PUMP TO CHASSIS - 776040Price on requestContact us for price and availability
28225408Ferrari Cylindrical Bushing - 225408$12.99Special order, ships in 7-14 days
2914040614Ferrari Flanged Nut 6mm - 14040614$0.27Available, ships in 3-6 days
30231619Ferrari Screw M6 x 22 - 231619$0.54Available, ships in 3-6 days
31851206Ferrari Pump Ground Cable - 851206$44.29Special order, ships in 7-14 days
32231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
33951205Ferrari Front Engine Compartment Ret - 951205$174.80Special order, ships in 7-14 days
34951196Ferrari Front Engine Compartment Del - 951196$204.34Special order, ships in 7-14 days
35263991Ferrari Clip - 263991$4.14Special order, ships in 7-14 days
36990708Ferrari TUBO RITORNO ANT. SOTTOP. - 990708$492.43Special order, ships in 7-14 days
37975692Ferrari Bracket With Sheath - 975692$96.01Special order, ships in 7-14 days
3885692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
3981649300Ferrari Clip - 81649300$13.55Special order, ships in 7-14 days
40866152Ferrari Clip - 866152$1.36Special order, ships in 7-14 days
41247440Ferrari Clip - 247440$1.30Available, ships in 3-6 days
42907920Ferrari Front Return Hose - 907920$295.43Special order, ships in 7-14 days
43774400Ferrari CLIP - 774400Price on requestContact us for price and availability
44990687Ferrari TUBO MANDATA ANT. SOTTOP. - 990687$344.69Special order, ships in 7-14 days
45262108Ferrari Screw Collar - 262108$3.47Special order, ships in 7-14 days
46907919Ferrari Front Delivery Hose - 907919$270.83Special order, ships in 7-14 days
47870079Ferrari Blocks - 870079$1,132.62Special order, ships in 7-14 days
48904930Ferrari RH Front Suspension Cooling - 904930$861.77Special order, ships in 7-14 days
49987751Ferrari FLEX. RAFFR. SOSP. ANT. SX - 987751$738.64Special order, ships in 7-14 days
50868787Ferrari Collar - 868787$5.86Special order, ships in 7-14 days
5116286224Ferrari Screw M6x25 - 16286224$4.77Special order, ships in 7-14 days
52841272Ferrari Gasket - 841272$15.51Special order, ships in 7-14 days
53231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
