Ferrari Portofino M — [VEHICLE TRIM] - E.32 - DOOR SEALS (diagram 0133)
Exploded view of the [vehicle trim] - e.32 - door seals on the Ferrari Portofino M, with 18 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [VEHICLE TRIM] - E.32 - DOOR SEALS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0133.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 829073 | Ferrari Round Stuffer - 829073 | Superseded | Order 939690 instead | |
| 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days | |
| 807171 | Ferrari Upper Windscreen Cross Membe - 807171 | Superseded | Order 959306 instead | |
| 1 | 959306 | Ferrari Windshield Cross Gasket - 959306 | $1,218.43 | Special order, ships in 7-14 days |
| 2 | 88272700 | Ferrari Guarnizione Giro Porta Infer - 88272700 | $145.74 | Special order, ships in 7-14 days |
| 3 | 89091800 | Ferrari Guarnizione Est.Filo Cint.Po - 89091800 | $500.40 | Special order, ships in 7-14 days |
| 3 | 89091900 | Ferrari RH Door Outer Perimeter Seal - 89091900 | $500.40 | Available, ships in 3-6 days |
| 4 | 89107900 | Ferrari Guarnizione Filo Cint.Int.Po - 89107900 | $500.40 | Special order, ships in 7-14 days |
| 4 | 89107800 | Ferrari LH Door Inner Perimeter Seal - 89107800 | $500.40 | Special order, ships in 7-14 days |
| 5 | 15689809 | Ferrari Screw D. 4.2 x 19 TBFIC - 15689809 | $0.27 | Available, ships in 3-6 days |
| 6 | 14115885 | Ferrari Fixing Block - 14115885 | $0.31 | Available, ships in 3-6 days |
| 7 | 826584 | Ferrari Screw - 826584 | $1.49 | Available, ships in 3-6 days |
| 8 | 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days |
| 9 | 819563 | Ferrari LH A-Pillar Adhesive Foam - 819563 | $8.78 | Special order, ships in 7-14 days |
| 9 | 819564 | Ferrari RH A-Pillar Adhesive Foam - 819564 | $8.78 | Special order, ships in 7-14 days |
| 10 | 939690 | Ferrari Round Stuffer - 939690 | $12.00 | Special order, ships in 7-14 days |
