Ferrari Purosangue — [GEARBOX] - C.04.01 - PTU SYSTEM (diagram 0045)

Exploded view of the [gearbox] - c.04.01 - ptu system on the Ferrari Purosangue, with 67 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Purosangue [GEARBOX] - C.04.01 - PTU SYSTEM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
14307924Ferrari Allen Screw 10x50 - 14307924SupersededOrder 14307934 instead
14305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
257823Ferrari Electric Fan Complete - 257823SupersededOrder 277070 instead
14039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
14307920Ferrari Screw - 14307920SupersededOrder 14307934 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
12643711Ferrari Washer - 12643711SupersededOrder 12643724 instead
12643721Ferrari Washer - 12643721SupersededOrder 12643724 instead
14499301Ferrari Washer - 14499301SupersededOrder 12643724 instead
155022255Ferrari Power Take Off Unit - 55022255SupersededOrder 55026462 instead
155026462Ferrari Power Take Off Unit - 55026462$48,161.27Contact us to order
1943858Ferrari Power Take Off Unit - 943858SupersededOrder 55026462 instead
214308734Ferrari Allen Screw 10x100 - 14308734$11.35Available, ships in 3-6 days
311190574Ferrari Washer - 11190574$0.13Available, ships in 3-6 days
414307934Ferrari Allen Screw M10 x 1.25 x 50 - 14307934$6.54Special order, ships in 7-14 days
5942844Ferrari Fastener Nut - 942844$37.18Special order, ships in 7-14 days
6925715Ferrari O Ring D.6.0 - 925715$1.02Available, ships in 3-6 days
7955262Ferrari Decoupling Gear - 955262$812.51Special order, ships in 7-14 days
814307834Ferrari Allen Screw 10x1.25x45 - 14307834$12.88Available, ships in 3-6 days
910441590Ferrari P Clip Bracket With Sheath 16mm - 10441590$0.98Available, ships in 3-6 days
1010441290Ferrari P Clip Bracket With Sheath 28mm D.10 - 10441290$1.02Available, ships in 3-6 days
11231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
1281290900Ferrari Screw With Double Washer - 81290900$1.42In stock
1315896211Ferrari Nut M6 x 5 - 15896211$0.13Available, ships in 3-6 days
1315896214Ferrari Nut M6 x 5 - 15896214SupersededOrder 14039614 instead
14195373Ferrari Rubber Support Pad - 195373$29.48Available, ships in 3-6 days
15776344Ferrari Compl. Oil Pipe Mounting Bra - 776344$49.22Special order, ships in 7-14 days
16278889Ferrari Rubber Ring - 278889$41.50Special order, ships in 7-14 days
17336484Ferrari Ring Clamp - 336484$15.72Special order, ships in 7-14 days
18225408Ferrari Cylindrical Bushing - 225408$12.99Special order, ships in 7-14 days
19858323Ferrari Ptu Oil Radiator - 858323$1,846.67Special order, ships in 7-14 days
20277070Ferrari Electric Fan Complete - 277070$467.15Special order, ships in 7-14 days
21749792Ferrari Lower Ptu Radiator Bracket - 749792$443.17Special order, ships in 7-14 days
21957554Ferrari Lower Ptu Radiator Bracket - 957554$566.30Special order, ships in 7-14 days
22847301Ferrari Tie-Rod On Ptu Oil Radiator - 847301$123.09Special order, ships in 7-14 days
23841863Ferrari Oil Delivery Pipe From Ptu T - 841863$837.14Special order, ships in 7-14 days
23998242Ferrari Oil Delivery Pipe From Ptu T - 998242$837.14Special order, ships in 7-14 days
24841862Ferrari Oil Return Pipe From Ptu To - 841862$837.14Special order, ships in 7-14 days
24998241Ferrari Oil Return Pipe From Ptu To - 998241$837.14Special order, ships in 7-14 days
25940339Ferrari Compl. Mpu Tank - 940339$418.56Special order, ships in 7-14 days
26919935Ferrari Mpu Tank Pipe Mounting Brack - 919935$36.92Special order, ships in 7-14 days
27138926Ferrari Rubber Spacer - 138926$8.72Available, ships in 3-6 days
2813577724Ferrari Washer - 13577724$3.68Special order, ships in 7-14 days
2910718011Ferrari Nut - 10718011$0.13Available, ships in 3-6 days
3014325140Ferrari Threaded Plug - 14325140$3.70Available, ships in 3-6 days
3212647878Ferrari Washer - 12647878$5.65Special order, ships in 7-14 days
3310442090Ferrari P Clip Bracket With Sheath D26 - 10442090$1.42Available, ships in 3-6 days
34254644Ferrari O-Ring Gasket - 254644$0.77Available, ships in 3-6 days
35231618Ferrari Allen Head Screw M6x20 TCEI - 231618$0.57Available, ships in 3-6 days
3684093700Ferrari Clip - 84093700$2.82Special order, ships in 7-14 days
37912593Ferrari Pipe Clip D20-D21 - 912593$0.96Special order, ships in 7-14 days
3810441890Ferrari P Clip Bracket With Sheath D22 - 10441890$1.17Available, ships in 3-6 days
39290935Ferrari Radiator Mounting Bush - 290935$12.67Available, ships in 3-6 days
40969955Ferrari Ptu Pipe Mounting Bracket - 969955$118.16Special order, ships in 7-14 days
4114040614Ferrari Flanged Nut 6mm - 14040614$0.27Available, ships in 3-6 days
43231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
4410441190Ferrari P clip Bracket With Sheath D8mm - 10441190$0.90Available, ships in 3-6 days
45272344Ferrari Stud Bolt - 272344$14.64Special order, ships in 7-14 days
4616296934Ferrari Screw 6x14 - 16296934$0.90Special order, ships in 7-14 days
4755022150Ferrari Staffa Supp. Centralina Mcm - 55022150$184.65Special order, ships in 7-14 days
4888187400Ferrari Spessore Di Regolaz.Ant. Sp. - 88187400$8.82Special order, ships in 7-14 days
4916286121Ferrari Screw M6 x 20 - 16286121$1.23Available, ships in 3-6 days
5012643724Ferrari/Maserati Washer - 12643724$0.20In stock
5214065921Ferrari Flanged Nut - 14065921$0.50Available, ships in 3-6 days
53943563Ferrari Compl. Mpu Carrier Bracket - 943563$393.93Special order, ships in 7-14 days
