Ferrari Roma Spider — [MECHANICAL SYSTEM] - D.2 - ENGINE FUEL DELIVERY PIPES (diagram 0049)

Exploded view of the [mechanical system] - d.2 - engine fuel delivery pipes on the Ferrari Roma Spider, with 15 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Roma Spider [MECHANICAL SYSTEM] - D.2 - ENGINE FUEL DELIVERY PIPES exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
293146Ferrari Clip - 293146$2.09Special order, ships in 7-14 days
206536Ferrari Clip D.14 - 206536$0.92Special order, ships in 7-14 days
771337Ferrari Fuel Pipe - 771337$636.39Special order, ships in 7-14 days
248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
1913291Ferrari Fuel Pipe - 913291$664.78Special order, ships in 7-14 days
1964815Ferrari Fuel Pipe - 964815$812.51Special order, ships in 7-14 days
2198253Ferrari Clip - 198253$7.40Special order, ships in 7-14 days
3879048Ferrari Blow-By Double Mounting Bracket - 879048$86.15Special order, ships in 7-14 days
414305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
4231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
5303789Ferrari RH Bracket - 303789$61.16Special order, ships in 7-14 days
6301717Ferrari LH Bracket - 301717$29.52Special order, ships in 7-14 days
7266156Ferrari Clip - 266156$1.28Special order, ships in 7-14 days
8257273Ferrari Clip D. 14-16 - 257273$2.59Special order, ships in 7-14 days

All Roma Spider diagrams
