Ferrari Roma Spider — [VEHICLE TRIM] - E.32 - DOOR SEALS (diagram 0133)
Exploded view of the [vehicle trim] - e.32 - door seals on the Ferrari Roma Spider, with 17 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [VEHICLE TRIM] - E.32 - DOOR SEALS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0133.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 902583 | Ferrari LH Lower Door Perimeter Seal - 902583 | Superseded | Order 902585 instead | |
| 829073 | Ferrari Round Stuffer - 829073 | Superseded | Order 939690 instead | |
| 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days | |
| 1 | 851809 | Ferrari Upper Windscreen Cross Member Seal - 851809 | $2,042.75 | Special order, ships in 7-14 days |
| 2 | 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days |
| 3 | 939690 | Ferrari Round Stuffer - 939690 | $12.00 | Special order, ships in 7-14 days |
| 4 | 851813 | Ferrari Tonneau Cover Seal - 851813 | $547.15 | Special order, ships in 7-14 days |
| 5 | 967500 | Ferrari LH Door Outer Perimeter Seal - 967500 | $525.26 | Special order, ships in 7-14 days |
| 5 | 967501 | Ferrari RH Door Outer Perimeter Seal - 967501 | $525.26 | Special order, ships in 7-14 days |
| 6 | 826584 | Ferrari Screw - 826584 | $1.49 | Available, ships in 3-6 days |
| 7 | 15689809 | Ferrari Screw D. 4.2 x 19 TBFIC - 15689809 | $0.27 | Available, ships in 3-6 days |
| 8 | 14115885 | Ferrari Fixing Block - 14115885 | $0.31 | Available, ships in 3-6 days |
| 9 | 902585 | Ferrari Lower Door Perimeter Seal - RH - 902585 | $262.62 | Special order, ships in 7-14 days |
| 10 | 851808 | Ferrari LH Door Inner Perimeter Seal - 851808 | $678.46 | Special order, ships in 7-14 days |
| 10 | 851811 | Ferrari RH Door Inner Perimeter Seal - 851811 | $678.46 | Special order, ships in 7-14 days |
