Ferrari Roma Spider — [ELECTRICAL SYSTEM] - F.12 - DCT GEARBOX SYSTEM (diagram 0187)
Exploded view of the [electrical system] - f.12 - dct gearbox system on the Ferrari Roma Spider, with 15 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [ELECTRICAL SYSTEM] - F.12 - DCT GEARBOX SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0187.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 834197 | Ferrari Buffer Battery - 834197 | $678.46 | Special order, ships in 7-14 days | |
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 291225 | Ferrari P clip Bracket With Sheath - 291225 | $7.86 | Special order, ships in 7-14 days | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 1 | 855811 | Ferrari DCT Gearbox ECU - Marelli - 855811 | $2,817.08 | Special order, ships in 7-14 days |
| 2 | 959281 | Ferrari DCT Cable - 959281 | $1,253.96 | Special order, ships in 7-14 days |
| 3 | 14059111 | Ferrari Flanged Nut M5 - 14059111 | $0.08 | Available, ships in 3-6 days |
| 3 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 4 | 863817 | Ferrari Buffer Battery - 863817 | $677.50 | Special order, ships in 7-14 days |
| 5 | 14040511 | Ferrari Nut - Self Locking - 14040511 | $1.11 | Special order, ships in 7-14 days |
| 6 | 10441490 | Ferrari/Maserati Retaining Clip - 10441490 | $1.35 | In stock |
| 7 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 8 | 10442290 | Ferrari P Clip Bracket With Sheath - 10442290 | $1.42 | Special order, ships in 7-14 days |
