Ferrari SF90 Spider — [GEARBOX] - C.02 - EXTERNAL GEARBOX CONTROLS (diagram 0042)
Exploded view of the [gearbox] - c.02 - external gearbox controls on the Ferrari SF90 Spider, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [GEARBOX] - C.02 - EXTERNAL GEARBOX CONTROLS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0042.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 864455 | Ferrari Rinvio P-Lock Cpl - 864455 | $441.81 | Special order, ships in 7-14 days | |
| 983379 | Ferrari Rinvio P-Lock Cpl - 983379 | Price on request | Contact us for price and availability | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 1 | 983649 | Ferrari Rinvio P-Lock Cpl - 983649 | $389.83 | Special order, ships in 7-14 days |
| 2 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
