Ferrari SF90 Stradale — [ENGINE] - B.27 - ENGINE TEMPERATURE AND PRESSURE REGULATORS (diagram 0032)
Exploded view of the [engine] - b.27 - engine temperature and pressure regulators on the Ferrari SF90 Stradale, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Stradale [ENGINE] - B.27 - ENGINE TEMPERATURE AND PRESSURE REGULATORS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-stradale/0032.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 276205 | Ferrari Oil Pressure Sensor - 276205 | Superseded | Order 328660 instead | |
| 318371 | Ferrari Oil Pressure Sensor - 318371 | Superseded | Order 328660 instead | |
| 14432221 | Ferrari Screw - 14432221 | Superseded | Order 231619 instead | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 14432224 | Ferrari Screw M6 x 22 - 14432224 | Superseded | Order 231619 instead | |
| 1 | 847660 | Ferrari Water Thermostat Housing - 847660 | $787.90 | Special order, ships in 7-14 days |
| 2 | 295159 | Ferrari Gasket - 295159 | $24.05 | Special order, ships in 7-14 days |
| 3 | 231620 | Ferrari/Maserati Screw - 231620 | $0.58 | In stock |
| 4 | 262913 | Ferrari Thermostat/Pressure Switch - 262913 | $371.08 | In stock |
| 5 | 231619 | Ferrari Screw M6 x 22 - 231619 | $0.54 | Available, ships in 3-6 days |
| 6 | 180137 | Ferrari/Maserati Water Temperature Sender / Sensor - 180137 | $25.19 | In stock |
| 7 | 328660 | Ferrari Oil Pressure Sensor - 328660 | $87.51 | Available, ships in 3-6 days |
| 8 | 269972 | Ferrari Oil Pressure Solenoid Valve - 269972 | $320.06 | Special order, ships in 7-14 days |
| 8 | 743032 | Ferrari Oil Pressure Solenoid Valve - 743032 | $344.69 | Special order, ships in 7-14 days |
| 9 | 233600 | Ferrari/Maserati Screw - 233600 | $1.98 | In stock |
| 10 | 873568 | Ferrari Paratia Elettrovalvola - 873568 | $155.10 | Special order, ships in 7-14 days |
| 10 | 859160 | Ferrari Solenoid Valve Shield - 859160 | $206.81 | Special order, ships in 7-14 days |
| 11 | 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days |
| 11 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
