Ferrari SF90 Stradale — [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK (diagram 0064)
Exploded view of the [mechanical system] - d.15 - expansion tank on the Ferrari SF90 Stradale, with 14 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Stradale [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-stradale/0064.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days | |
| 1 | 939126 | Ferrari Coolant Reservoir - 939126 | $393.93 | Special order, ships in 7-14 days |
| 2 | 926021 | Ferrari Bracket - 926021 | $393.93 | Special order, ships in 7-14 days |
| 3 | 857091 | Ferrari Hex Head Screw M6X135 - 857091 | $7.42 | Special order, ships in 7-14 days |
| 4 | 12644424 | Ferrari Washer 6.15-15 x 1 - 12644424 | $0.12 | Available, ships in 3-6 days |
| 5 | 863292 | Ferrari Clip - 863292 | $61.26 | Special order, ships in 7-14 days |
| 6 | 145030 | Ferrari Radiator Cap - 145030 | $89.98 | In stock |
| 7 | 924062 | Ferrari Rubber Pipe - 924062 | $236.34 | Special order, ships in 7-14 days |
| 8 | 262559 | Ferrari Clip - 262559 | $1.78 | Available, ships in 3-6 days |
| 9 | 776284 | Ferrari Tubo Rigido Drenaggio - 776284 | $152.62 | Special order, ships in 7-14 days |
| 9 | 865205 | Ferrari Tubo Rigido Drenaggio - 865205 | Superseded | Order 776284 instead |
| 10 | 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days |
