Ferrari F8 Spider — [VEHICLE TRIM] - E.16 - REAR SHIELDS (diagram 0115)

Exploded view of the [vehicle trim] - e.16 - rear shields on the Ferrari F8 Spider, with 71 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari F8 Spider [VEHICLE TRIM] - E.16 - REAR SHIELDS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
103516Ferrari Cable Grommet - 103516SupersededOrder 10396480 instead
300832Ferrari Engine Buffer - 300832SupersededOrder 87546300 instead
14228076Ferrari Plate - 14228076$3.68Special order, ships in 7-14 days
68313900Ferrari Plate - 68313900$0.44Special order, ships in 7-14 days
248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
12640606Ferrari Washer - 12640606SupersededOrder 12640678 instead
12640608Ferrari Washer - 12640608SupersededOrder 12640678 instead
12640677Ferrari Washer - 12640677SupersededOrder 12640678 instead
14498804Ferrari Washer - 14498804SupersededOrder 14498824 instead
1897339Ferrari Complete Rear Underbody Shield - 897339$1,132.62Special order, ships in 7-14 days
2909340Ferrari Rear Chassis Reinforcement - 909340$1,329.59Special order, ships in 7-14 days
3768520Ferrari RH Rear Lateral Dam - 768520$184.65Special order, ships in 7-14 days
4768518Ferrari LH Rear Lateral Dam - 768518$184.65Special order, ships in 7-14 days
585833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
612643701Ferrari Flat Washer - 12643701$0.12Available, ships in 3-6 days
710902824Ferrari Screw M6 x 30 - 10902824$0.17Available, ships in 3-6 days
814305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
8231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
912640624Ferrari Plain Washer 6mm - 12640624$0.31Available, ships in 3-6 days
10762216Ferrari Compl. RH Engine Air Vent Du - 762216$206.81Special order, ships in 7-14 days
11762226Ferrari Compl. LH Engine Air Vent Du - 762226$206.81Special order, ships in 7-14 days
1213290024Ferrari Screw M6 x 14 TCIC PZ - 13290024$0.82Available, ships in 3-6 days
1314642294Ferrari Rivet - 14642294$1.36Available, ships in 3-6 days
1481290900Ferrari Screw With Double Washer - 81290900$1.42In stock
1583442900Ferrari Body Screw - 83442900$1.51In stock
1670006753Ferrari Compl. RH Engine Compartment - 70006753$17,929.96Contact us to order
16938571Ferrari Paratia Est.Dx Cpl Vano Mot. - 938571$6,343.24Special order, ships in 7-14 days
16914792Ferrari Paratia Estet. Vano Mot. Dx - 914792$320.06Special order, ships in 7-14 days
1770006754Ferrari Compl. LH Engine Compartment - 70006754$17,929.96Contact us to order
17938572Ferrari Paratia Est.Sx Cpl Vano Mot. - 938572$6,343.24Special order, ships in 7-14 days
17914790Ferrari Paratia Estet. Vano Mot. Sx - 914790$320.06Special order, ships in 7-14 days
1812640678Ferrari Washer 6.15x25x2 - 12640678$3.47Available, ships in 3-6 days
1985797600Ferrari Special Screw - 85797600$59.07Available, ships in 3-6 days
2086921700Ferrari Central Cosmetic Shield Complete - 86921700$68.92Special order, ships in 7-14 days
2086935100Ferrari Central Cosmetic Shield Complete - 86935100$1,969.79Special order, ships in 7-14 days
2070006751Ferrari Compl. Central Cosmetic Shie - 70006751$16,398.65Contact us to order
2165864100Ferrari Allen Head Screw M6 x 15 TBFEI - 65864100$2.82Available, ships in 3-6 days
2287546300Ferrari Engine Buffer Complete - 87546300$344.69Special order, ships in 7-14 days
2313027024Ferrari Screw TCEI M6 x 16 - 13027024$0.38Special order, ships in 7-14 days
2410523401Ferrari Washer - 10523401$0.84Available, ships in 3-6 days
2512646678Ferrari Washer - 12646678$1.49Available, ships in 3-6 days
26880465Ferrari Presa Aria Freni Post. Dx Cp - 880465$204.34Special order, ships in 7-14 days
27880475Ferrari Presa Aria Freni Post. Sx Cp - 880475$204.34Special order, ships in 7-14 days
28965227Ferrari Piastrina Matricola Spider - 965227$189.56Special order, ships in 7-14 days
29815004Ferrari Vasca Ricovero RHt Cpl - 815004$664.78Special order, ships in 7-14 days
29985815004Ferrari Vasca Ricovero RHt Cpl - 985815004Price on requestContact us for price and availability
30815007Ferrari Riparo Calore Vasca RHt - 815007$590.91Special order, ships in 7-14 days
31872545Ferrari Tappo Risuonatore Dx Vasca C - 872545$13.01Special order, ships in 7-14 days
32874789Ferrari Tappo Risuonatore Sx Vasca C - 874789$13.01Special order, ships in 7-14 days
33877468Ferrari Kit Guarnizione Vasca RHt - 877468$853.55Special order, ships in 7-14 days
34867730Ferrari Compl. Roof Tub Soundproofin - 867730$787.90Special order, ships in 7-14 days
3582201000Ferrari Roof Tub Seal - 82201000$443.17Special order, ships in 7-14 days
36914800Ferrari Compl. RH Inner Bracket - Engine Compartment Cosmetic Shield - 914800$204.34Special order, ships in 7-14 days
37914796Ferrari Compl. LH Inner Bracket - Engine Compartment Cosmetic Shield - 914796$103.38Special order, ships in 7-14 days
38917502Ferrari Compl. RH Outer Bracket Engine Compartment Cover - 917502$76.30Special order, ships in 7-14 days
39917504Ferrari Compl. LH Outer Bracket Engine Comnpartment Cover - 917504$76.30Special order, ships in 7-14 days
40779083Ferrari Rear Cosmetic Shield - 779083$418.56Special order, ships in 7-14 days
40839111Ferrari REAR COSMETIC SHIELD - 839111Price on requestContact us for price and availability
4086880800Ferrari Rear Cosmetic Shield - 86880800$320.06Special order, ships in 7-14 days
4183911400Ferrari Water Drain Pipe - 83911400$29.48Special order, ships in 7-14 days
4284324400Ferrari COSMETIC CAP - 84324400$2.36Available, ships in 3-6 days
4314228074Ferrari Plate - 14228074Price on requestContact us for price and availability
4414183376Ferrari Screw Clip - 14183376$0.19Available, ships in 3-6 days
44768645Ferrari Type A Plate For Pin - 768645$0.98Special order, ships in 7-14 days
4516286127Ferrari Screw 6x20 - 16286127$0.82Available, ships in 3-6 days
46317169Ferrari Screw - 317169$2.82Available, ships in 3-6 days
4767315400Ferrari Washer - 67315400$0.82Special order, ships in 7-14 days
4810396480Ferrari Cable Grommet - 10396480$3.99Available, ships in 3-6 days
49914793Ferrari RH Engine Comp. Cosmetic Shi - 914793$52.50Special order, ships in 7-14 days
50914789Ferrari LH Engine Comp. Cosmetic Shi - 914789$52.50Special order, ships in 7-14 days

All F8 Spider diagrams
