Ferrari SF90 XX Stradale — [VEHICLE TRIM] - E.59 - EXTERNAL LATERAL TRIM (diagram 0172)
Exploded view of the [vehicle trim] - e.59 - external lateral trim on the Ferrari SF90 XX Stradale, with 49 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Stradale [VEHICLE TRIM] - E.59 - EXTERNAL LATERAL TRIM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-stradale/0172.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days | |
| 1 | 985857535 | Ferrari Compl. RH Underdoor Trim - 985857535 | $30,070.74 | Contact us to order |
| 1 | 985876381 | Ferrari COMPL. RH UNDERDOOR TRIM - 985876381 | Price on request | Contact us for price and availability |
| 1 | 995038 | Ferrari COMPL. RH UNDERDOOR TRIM - 995038 | Price on request | Contact us for price and availability |
| 1 | 995039 | Ferrari COMPL. RH UNDERDOOR TRIM - 995039 | $64,487.33 | Contact us to order |
| 2 | 985857534 | Ferrari Compl. LH Underdoor Trim - 985857534 | $30,070.74 | Contact us to order |
| 2 | 985876382 | Ferrari COMPL. LH UNDERDOOR TRIM - 985876382 | Price on request | Contact us for price and availability |
| 2 | 995033 | Ferrari COMPL. LH UNDERDOOR TRIM - 995033 | Price on request | Contact us for price and availability |
| 2 | 995034 | Ferrari COMPL. LH UNDERDOOR TRIM - 995034 | Price on request | Contact us for price and availability |
| 3 | 856513 | Ferrari RH Sill Rear Fastener Bracket - 856513 | $34.44 | Special order, ships in 7-14 days |
| 4 | 856512 | Ferrari LH Sill Rear Fastener Bracket - 856512 | $34.44 | Special order, ships in 7-14 days |
| 5 | 867842 | Ferrari Batticalcagno Est Carbonio D - 867842 | $1,649.69 | Special order, ships in 7-14 days |
| 5 | 989176 | Ferrari COMPL. RH OUTER KICKPLATE - 989176 | $4,973.75 | Special order, ships in 7-14 days |
| 6 | 867843 | Ferrari Batticalcagno Est Carbonio S - 867843 | $1,649.69 | Special order, ships in 7-14 days |
| 6 | 989175 | Ferrari COMPL. LH OUTER KICKPLATE - 989175 | $7,801.84 | Special order, ships in 7-14 days |
| 7 | 80874200 | Ferrari Screw M6 x 22 - 80874200 | $1.59 | Available, ships in 3-6 days |
| 8 | 907312 | Ferrari Hex Head Screw M6X18 with Washer - 907312 | $10.25 | Special order, ships in 7-14 days |
| 9 | 83442900 | Ferrari Body Screw - 83442900 | $1.51 | In stock |
| 10 | 11625824 | Ferrari Screw 6x18 - 11625824 | $0.71 | Available, ships in 3-6 days |
| 11 | 902186 | Ferrari Compl. RH Rear Wheel Flick - 902186 | $2,642.81 | Special order, ships in 7-14 days |
| 11 | 991698 | Ferrari COMPL. RH REAR WHEEL FLICK - 991698 | Price on request | Contact us for price and availability |
| 12 | 902185 | Ferrari Compl. LH Rear Wheel Flick - 902185 | $2,642.81 | Special order, ships in 7-14 days |
| 12 | 991696 | Ferrari COMPL. LH REAR WHEEL FLICK - 991696 | Price on request | Contact us for price and availability |
| 13 | 113647 | Ferrari Nyloc Nut - 113647 | $0.52 | Available, ships in 3-6 days |
| 14 | 12647778 | Ferrari Cup Washer - 12647778 | $0.82 | Available, ships in 3-6 days |
| 15 | 871934 | Ferrari Assorbitore Intercooler Late - 871934 | $81.23 | Special order, ships in 7-14 days |
| 16 | 871933 | Ferrari Assorbitore Intercooler Late - 871933 | $81.23 | Special order, ships in 7-14 days |
| 17 | 85834000 | Ferrari Screw M5 x 25 - 85834000 | $0.71 | Special order, ships in 7-14 days |
| 18 | 770253 | Ferrari Compl. RH Rear Bulkhead Trim - 770253 | $7,661.14 | Special order, ships in 7-14 days |
| 18 | 889476 | Ferrari Compl. RH Rear Bulkhead Trim - 889476 | $7,119.43 | Special order, ships in 7-14 days |
| 18 | 995064 | Ferrari COMPL. RH REAR BULKHEAD TRIM - 995064 | Price on request | Contact us for price and availability |
| 18 | 995065 | Ferrari COMPL. RH REAR BULKHEAD TRIM - 995065 | Price on request | Contact us for price and availability |
| 19 | 770168 | Ferrari Compl. LH Rear Bulkhead Trim - 770168 | $7,644.73 | Special order, ships in 7-14 days |
| 19 | 889228 | Ferrari Compl. LH Rear Bulkhead Trim - 889228 | $7,103.02 | Special order, ships in 7-14 days |
| 19 | 995068 | Ferrari COMPL. LH REAR BULKHEAD TRIM - 995068 | Price on request | Contact us for price and availability |
| 19 | 995069 | Ferrari COMPL. LH REAR BULKHEAD TRIM - 995069 | Price on request | Contact us for price and availability |
| 20 | 70006976 | Ferrari Centre Rear Bulkhead Trim - 70006976 | $17,560.99 | Contact us to order |
| 20 | 916310 | Ferrari Centre Rear Bulkhead Trim - 916310 | $1,674.30 | Special order, ships in 7-14 days |
| 20 | 909514 | Ferrari Fin.Paratia Post.Centr.Opt C - 909514 | $6,333.85 | Special order, ships in 7-14 days |
| 21 | 950930 | Ferrari Fuel Drain Bowl - 950930 | $517.04 | Special order, ships in 7-14 days |
| 22 | 897540 | Ferrari Vite M6X14 Con Ros Imp 5.5X1 - 897540 | $13.97 | Special order, ships in 7-14 days |
| 23 | 933595 | Ferrari Compl. Fluid Drain Pipe - 933595 | $492.43 | Special order, ships in 7-14 days |
| 24 | 161490 | Ferrari Hose Clip 12 - 20 x 9 - 161490 | $3.91 | Available, ships in 3-6 days |
| 25 | 10441490 | Ferrari/Maserati Retaining Clip - 10441490 | $1.35 | In stock |
| 26 | 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days |
| 27 | 750056 | Ferrari Compl. Rear Node Tray Bracke - 750056 | $49.22 | Special order, ships in 7-14 days |
| 28 | 898128 | Ferrari Vite M6X50 Con Roset.Imp.5.5 - 898128 | $17.67 | Special order, ships in 7-14 days |
